| Item 型号 | 橡胶硬度 IRHD(daN/mm) | A | H | B | M | FxE | CF | L | S | 平均负荷(Kg/mm) | 最大荷重(kg) | 最大压缩量(mm) |
| SE60M12 | 45 | 80 | 38 | 60 | M12 | 14*11 | 100 | 120 | 3 | 9 | 36 | 4 |
| SE60M12 | 50 | 80 | 38 | 60 | M12 | 14*11 | 100 | 120 | 3 | 13 | 52 | 4 |
| SE60M12 | 60 | 80 | 38 | 60 | M12 | 14*11 | 100 | 120 | 3 | 16 | 64 | 4 |
| SE60M12 | 70 | 80 | 38 | 60 | M12 | 14*11 | 100 | 120 | 3 | 24 | 96 | 4 |
| SE75M16 | 35 | 104 | 50 | 75 | M16 | 30*13 | 140 | 187 | 4 | 16 | 80 | 5 |
| SE75M16 | 45 | 104 | 50 | 75 | M16 | 30*13 | 140 | 187 | 4 | 24 | 120 | 5 |
| SE75M16 | 60 | 104 | 50 | 75 | M16 | 30*13 | 140 | 187 | 4 | 38 | 190 | 5 |
| SE75M16 | 70 | 104 | 50 | 75 | M16 | 30*13 | 140 | 187 | 4 | 60 | 300 | 5 |
| SE75M16 | 80 | 104 | 50 | 75 | M16 | 30*13 | 140 | 187 | 4 | 95 | 475 | 5 |
